ESD Heel Straps for Operator Grounding – Eurostat

30-560-0044

Eurostat ESD heel straps: conductive ribbon for shoe insertion, built-in 1.5 MΩ resistor. Point-to-point resistance < 10⁹ Ω. IEC 61340-5-1 compliant. Eurostat marking.

Lenght

Our catalogue is available for browsing. Account access and cart features are currently being optimized. Those services will be available again very soon. Thank you for your understanding.

Please contact us for this article


ESD Heel Straps for Operator Grounding – Eurostat

Eurostat ESD heel straps ensure continuous operator grounding in EPA zones. The conductive ribbon is inserted into the shoe or sock and held under the heel by a double-layer elastomer cup. Must be worn on both feet.

Conductive ribbon:

  • ✓ Surface resistance: ≤ 10⁵ Ω
  • ✓ Length: 57 cm (ref. 30-560-0044) / 45 cm for high-heel shoes (ref. 30-560-0053)

Double-layer conductive rubber cup:

  • ✓ Outer surface: conductive, black – surface resistance ≤ 10⁵ Ω
  • ✓ Inner surface: antistatic, ivory – surface resistance ≤ 10¹¹ Ω
  • ✓ Point-to-point resistance: < 10⁹ Ω
  • ✓ Built-in safety resistor: 1.5 MΩ
  • ✓ Marking: Eurostat

Compliance: IEC 61340-5-1
