ESD Knipex 64 62 120 Cutting Pliers – Oblique...
ESD Knipex 64 62 120 Cutting Pliers – Oblique Mini-Blade Mirror Polished

ESD Knipex 64 62 120 Cutting Pliers – Oblique Mini-Blade Mirror Polished

45-060-2001

ESD Knipex 64 62 120 cutting pliers: oblique end cutter mini-blade α=65°, mirror polished. Rs <10⁵ Ω, IEC 61340, REACH. 120mm, 70g. Soft wire Ø 0.6mm max. For sensitive components.

Our catalogue is available for browsing. Account access and cart features are currently being optimized. Those services will be available again very soon. Thank you for your understanding.

Please contact us for this article


ESD Knipex 64 62 120 Cutting Pliers – Eurostat

ESD Knipex 64 62 120 cutting pliers are precision pliers with oblique end cutter and mini-blade at low angle (α=65°) for ultra-clean cuts on delicate components and wires in EPA zones.

  • ✓ Oblique end cutter, mini-blade with small bevel α = 65°
  • ✓ Head: mirror polished
  • ✓ Handles: with multi-component grips
  • ✓ Weight: 70g
  • ✓ Dimensions: 120 × 66 × 17mm
  • ✓ Standard: DIN ISO 9654 & DIN EN 61340-5
  • ✓ Cutting capacity soft wire: Ø 0.6mm
  • ✓ Head width (A): 11mm – Jaw length (B): 20mm
  • ✓ Jaw thickness (D): 7mm – Cutting edge length (C): 7mm
  • ✓ Surface resistance: < 10⁵ Ω – REACH compliant
  • ✓ Brand: Knipex
ESD property
Dissipatif
