26-103-0019

Black conductive ESD polyurethane foam for cushioning and shielding components in EPA packaging. Flexible open-cell structure, surface resistance < 105 Ω, compliant with IEC 61340-5-1 and RoHS.

Dimensions

Our catalogue is available for browsing. Account access and cart features are currently being optimized. Those services will be available again very soon. Thank you for your understanding.

Please contact us for this article


Conductive ESD Polyurethane Foam for Cushioning & Shielding

Eurostat conductive ESD polyurethane foam cushions and protects electronic components while boosting the shielding properties of the packaging. Its flexible open-cell structure absorbs shocks, and its conductive latex impregnation gives it a surface and volume resistance below 105 Ω and a decay time from 1000 V to 100 V in under two seconds. Compliant with IEC 61340-5-1 and the RoHS directive, it can be cut into custom inserts for boxes and transport cases. Note: this conductive foam should not be placed in direct contact with some ESD-sensitive devices — it is intended for cushioning and shielding rather than direct contact.

  • ✓ Material: PU foam with conductive latex impregnation
  • ✓ Colour: black, flexible open cells
  • ✓ Surface resistance: < 105 Ω (IEC 61340-3-2)
  • ✓ Volume resistance: < 105 Ω
  • ✓ Decay time: 1000 V to 100 V in under 2 seconds
  • ✓ Density: 24 kg/m³, hardness 120-140 N (BS4443), class A (BS3379)
  • ✓ Tensile strength: 70 kPa, elongation at break 100%
  • ✓ Ideal for cushioning, shock absorption and shielding in EPA packaging
  • ✓ Not to be placed in direct contact with some ESD-sensitive devices
  • ✓ Formats: 400x300 mm and 600x400 mm (3 and 6 mm thick), 2000x1000 mm sheets, custom cutting
  • ✓ Compliant with IEC 61340-5-1 and RoHS
